LCD AND USB CONFIGURATION
LCD displays
LCD and USB Configuration
C
H
A
P
T
E
R
4
..................................................................................
T his chapter addresses module specifics pertaining to the LCD and USB
interfaces.
See the application note “LCD Displays Supported by the NetSilicon NS9750/NS9360
Processors” (available on http://www.digiembedded.com) for additional
information about the application-specific configuration and capabilities of the LCD
controller on the ConnectCore 9C/Wi-9C module.
LCD displays
There are seven categories of LCD displays, all of which the module supports:
?
Color TFT ( thin film transistor , also called active matrix (AM)):
–
18-bit
?
Six types of STN ( super twisted nematic , also called passive matrix (PM)):
–
–
Three single panel displays
Three dual panel displays
Each STN display is either color or monochrome:
–
–
Color display: Up to 8-pin using color-enhancing palette RAM
Monochrome display: Up to 8-pin or 4-pin using grayscale-enhancing palette
RAM
Control and data
pins
The ConnectCore 9C/Wi-9C LCD interface has six control pins. The number of data
pins depends on the display type. Displays typically require 4 – 6 control pins. The
next two tables list the control pins and the data pins, respectively.
www.digiembedded.com
Note:
Most of the pins on the Wi-9C, if not used, can be left floating. The pins that
cannot be left floating are ones that are required (power, ground, UBUFFEN,
etc).
59
